SortsTypeParameters
SystemOperating systemLinux
Online visitorSupports 4 visitors viewing at the same time.
APPO-KAM Pro
CollectionCPUT23
Memory512Mb
Image sensorGC2083,1/3CMOS
Minimum illumination0.8Lux/F1.4(Color mode),0.3Lux/F1.4(B&W mode)
LensStandard lens 14mm
Sensor performanceSupports automatic white balance, automatic gain control, and automatic backlight compensation.
PTZHorizontal 305 °, vertical 100 °
Viewing angleD100° diagonal
VideoNight VisionColor night vision, dual light source, 6 dual color lights
Compression standardH.264 /MJPEF/JPEG
Data rateMain stream: 1296P/15fps, sub stream: 360P/15fps
IR controlWhen the IR night vision function is enabled, IR and ICR are automatically detected; when the IR  night vision function is disabled, IR is off and ICR is fixed in the day vision mode.
Bit rateCBR/VBR two rate control modes, with an output rate range of 128 to 4096kbps.
Image adjustmentBrightness, contrast, vertical, horizontal adjustable, OSD display.
AudioInputBuilt-in-38dB microphone
OutputBuilt-in 8Ω1W speaker
Sampling frequency/bit width8KHz/16bit
Compression standard/Bit RateG711A
AIHumanoid detectionHumanoid detection, filtering invalid alarm events.
Area detectionCustomize detection zones, only monitor areas that matter.
Intelligent notification soundSet different notification sounds for different devices, so that you can accurately determine which device is triggered.
Intelligent alarm soundSet different alarm sounds based on different scenarios.
More AI functions (under testing)Pets, vehicles, packages, etc
NetworkNetwork protocolTCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P,IPV4等
Wireless networkIEEE802.11b/g/n
Wireless frequency2.4~2.4835GHz
Wireless security encryption64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption
Wireless connection methodAP hotspot, Scan QR code, Bluetooth
KeyKey 1On/Off
Reset keyLong press to restore factory settings
StorageExternal TF cardSupports T-Flash cards (up to 256GB)
Cloud storageFree cloud storage,1 day loop(China),3-day loop( Overseas)
AlarmSound light alarmSound light alarm,6 infrared and 6 white,full-color night vision cameras
Alarm detectionSupports PIR human movement detection, detection range 10 meters
Physical IndicatorsCharging voltageDC5V±5%
Power supplyBuilt in 20000mAh battery,4*21700
Power consumptionSleep current 300uA, working: 230ma-1.5A max
Operating conditionTemperature: -10~55℃; Humidity: <90%
WeightGross weight:   (Note: in kind prevail)
Size
What's in the boxCamera * 1, MICRO USB cable * 1, manual * 1, (optional solar panel * 1 and solar panel bracket * 1 )
