Ultra-Low Series
QG5
VeePai cloud platform is a multi-functional smart platform under VeePai that integrates cloud storage, cloud control and other functions.
Contact Us
| Sorts | Type | Parameters |
| System | Operating system | Linux |
| Online visitor | Supports 4 visitors viewing at the same time. | |
| APP | O-KAM Pro | |
| Collection | CPU | T23 |
| Memory | 512Mb | |
| Image sensor | GC2083+GC2083 1/3CMOS | |
| Minimum illumination | 0.8Lux/F1.4(Color mode),0.3Lux/F1.4（B&W mode） | |
| Lens | Standard lens 14mm | |
| Sensor performance | Supports automatic white balance, automatic gain control, and automatic backlight compensation. | |
| PTZ | Horizontal 305 °, vertical 100 ° | |
| Viewing angle | D100°diagonal | |
| Video | Night Vision | Color night vision, dual light source, 6 dual color lights |
| Compression standard | H.264 /MJPEF/JPEG | |
| Data rate | Main stream: 1296P/15fps, sub stream: 360P/15fps | |
| IR control | When the IR night vision function is enabled, IR and ICR are automatically detected; when the IR night vision function is disabled, IR is off and ICR is fixed in the day vision mode. | |
| Bit rate | CBR/VBR two rate control modes, with an output rate range of 128 to 4096kbps. | |
| Image adjustment | Brightness, contrast, vertical, horizontal adjustable, OSD display. | |
| Audio | Input | Built-in-38dB microphone |
| Output | Built-in 8Ω2W speaker | |
| Sampling frequency/bit width | 8KHz/16bit | |
| Compression standard/Bit Rate | G711A | |
| AI | Humanoid detection | Humanoid detection, filtering invalid alarm events. |
| Area detection | Customize detection zones, only monitor areas that matter. | |
| Intelligent notification sound | Set different notification sounds for different devices, so that you can accurately determine which device is triggered. | |
| Intelligent alarm sound | Set different alarm sounds based on different scenarios. | |
| More AI functions (under testing) | Pets, vehicles, packages, etc | |
| Network | Wireless connection | Scan the device QR code to add/scan the APP QR code |
| China Cat1 | FDD:B1/B3/B5/B8 TDD:B34/B38/B39/B40/B41 | |
| Overseas Cat4 | European/Japanese/American/Australian versions | |
| Key | Key 1 | On/Off |
| Reset key | Long press to restore factory settings | |
| Storage | Micro SD card | Supports Micro SD card (up to 256GB) |
| Cloud storage | Free cloud storage: 1-day loop recording(China), 3-day loop recording(Overseas) | |
| Alarm | Sound light alarm | Sound and light alarm, 6 infrared lights+6 white lights, full-color night vision |
| Alarm detection | Supports PIR human movement detection, detection range 10 meters | |
| Rated voltage | DC5V±5% | |
| Power supply | Built in 12000mAh battery，3*21700 | |
| Power consumption | Sleep standby 300uA, working: 400MA-1.5A max | |
| Operating condition | Temperature: -10～55℃; Humidity: ＜90% | |
| Weight | Gross weight: （Note: in kind prevail） | |
| Size | ||
| What's in the box | Camera * 1, MICRO USB cable * 1, manual * 1, (solar panel * 1, solar panel bracket * 1 optional) |
